Thermodynamic Potential
Thermodynamic potential or fundamental function is a quantity used to represent the state of a system or is the energy functions formed be the combining the basic thermodynamic variables.
The types of Thermodynamic Potential
- Internal Energy
- Enthalpy
- Helmholtz energy function
- Gibbs free energy
- Internal Energy
The energy possessed by the system due to molecular constitution is called internal energy. When a system passes from one state to another state, the internal energy depends on initial and final state and doesn't depend on path followed which is known as state function.
The internal energy of a system is denoted by the symbol "U" and is typically expressed in units of energy (such as joules or calories). It is an extensive property, meaning it depends on the amount or quantity of substance present in the system.
The internal energy of a system can change due to various factors, such as heat transfer (thermal energy exchange) and work done on or by the system. When heat is added to a system or work is done on it, the internal energy increases. Conversely, when heat is lost from the system or work is done by the system, the internal energy decreases.
The change in internal energy (ΔU) of a system is given by the equation:
ΔU = Q - W
where:
ΔU is the change in internal energy
Q is the heat added to the system
W is the work done on the system
Internal energy is a state function, which means it depends only on the current state of the system and not on the path taken to reach that state. It can be related to other thermodynamic properties, such as temperature, pressure, and volume, through various equations and laws, such as the First Law of Thermodynamics.
Overall, the internal energy of a system is a crucial quantity in thermodynamics, as it represents the total energy content and plays a significant role in understanding and analyzing energy transfers and transformations in physical and chemical processes.
Figure 1:Molecules experiencing internal energy
- Enthalpy
The total energy of thermodynamically system is called enthalpy. It is a heat function at constant pressure.
It is denoted by the symbol "H" and is a function of the internal energy, pressure, and volume of the system. Enthalpy is particularly useful in the study of chemical reactions and phase changes.
The enthalpy of a system can be thought of as the amount of heat absorbed or released by the system during a process at constant pressure. When a chemical reaction occurs at constant pressure, the change in enthalpy (ΔH) is equal to the heat exchanged between the system and its surroundings.
Enthalpy is defined as:
H = U + PV
where:
H is the enthalpy of the system
U is the internal energy of the system
P is the pressure of the system
V is the volume of the system
Enthalpy is an extensive property, meaning it depends on the quantity of the substance or the size of the system. The standard enthalpy change of a reaction (ΔH°) refers to the enthalpy change when all reactants and products are in their standard states at a specified temperature and pressure.
Enthalpy is often used in various fields of science and engineering, such as chemistry, physics, and thermodynamics, to analyze and predict the energy changes associated with processes and reactions.
Figure 2: Enthalpy
- Helmholtz Function
The energy function of thermodynamic system, which changes due to external work applied on the isothermal process.
It is denoted by the symbol "F" or "A" and is named after the German physicist Hermann von Helmholtz.
The Helmholtz function is defined as:
F = U - TS
where:
F is the Helmholtz function
U is the internal energy of the system
T is the absolute temperature of the system
S is the entropy of the system
The Helmholtz function combines information about both the internal energy and entropy of a system. It represents the maximum amount of work that can be extracted from a system at constant temperature and volume. In other words, it is a measure of the system's capacity to do useful work.
The Helmholtz function is particularly useful in systems at constant temperature and volume, such as closed systems or systems undergoing reversible processes. The change in Helmholtz function (ΔF) for a process occurring at constant temperature and volume is equal to the maximum useful work that can be obtained from the system during the process.
The Helmholtz function is related to other thermodynamic potentials, such as the internal energy (U), enthalpy (H), and Gibbs free energy (G). These potentials are related through various thermodynamic equations and can be used to analyze and predict the behavior of a system under different conditions.
- Gibbs free energy
It is a energy function of thermodynamic system which remains constant under the process of isothermal and isobaric.
It is named after the American physicist Josiah Willard Gibbs.
The Gibbs free energy is defined as:
G = H - TS
where:
G is the Gibbs free energy
H is the enthalpy of the system
T is the absolute temperature of the system
S is the entropy of the system
The Gibbs free energy combines information about the enthalpy and entropy of a system. It represents the maximum amount of useful work that can be extracted from a system at constant temperature and pressure.
For a chemical reaction occurring at constant temperature and pressure, the change in Gibbs free energy (ΔG) is related to the spontaneity of the reaction. If ΔG is negative, the reaction is spontaneous in the forward direction and releases free energy. If ΔG is positive, the reaction is non-spontaneous in the forward direction and requires an input of free energy. If ΔG is zero, the reaction is at equilibrium.
The Gibbs free energy is particularly useful in determining the equilibrium conditions of a system and predicting the direction in which a reaction will proceed. It allows us to assess the balance between enthalpy and entropy contributions and determine whether a process is thermodynamically favorable.
The Gibbs free energy is related to other thermodynamic potentials, such as the internal energy (U), enthalpy (H), and Helmholtz function (F). These potentials are connected through various thermodynamic equations and provide valuable insights into the behavior of a system under different conditions.
Figure 4: Significance of Gibbs free energy
